FORKS
Robust cast iron forks, highly resistant to torsion and impact.
TILLER EVOLUTION
Fully integrated ergonomic technopolymer tiller system including finger tip throttle and proportional fork controls, safety pushbutton, horn, turtle button, hourmeter, battery status indicator as standard equipment.
MOTORS
Lifting and traction motors have both a voltage of 24 Volt. The vertical assembly not only allows a more rapid access to all the parts but also minimizes room cluttering-up and wiring stress.
TECHNOLOGY AND SAFETY
The powerful ZAPI ACEX controller is connected to 3 sensors that automatically adjust speed control and reduce it up to 6 km/h when at least one of the following events occurs:
1. Lateral protection guards are not raised and are not brought to the “run” position.
2. The turning radius sensor registers a curve with an angle over 8 degrees.
3. The footplate is kept in closed position.
WHEELS
Wheel drive of considerable power and big size. Two stabilizing wheels enable movement even on more difficult surfaces, thus
guaranteeing maximum stability in any condition of use.
REPLACEMENT OF BATTERIES
The battery compartment is equipped with a removable side frame and an internal roller that minimizes effort during the battery extraction and connection phases. A trolley is also available upon request to replace the battery rapidly.
ROLLERS
Standard configuration provided with tandem polyurethane rollers. Available single rollers as optional.
